Boss VE-5 User Manual

4
Easy Quick Guide
Easy Quick Guide
1
3
Install Batteries
page 3
/Connect an AC Adaptor
page 10
First, install batteries “Installing Batteries” (p. 3)
or, connect an AC adaptor (BOSS PSA series; sold separately)
“Connections” (p. 10)
Turn the Power On
Hold down the [ ] button until
the power turns on.
OK even if you don’t have a mic
The VE-5 has an internal mic. The internal
mic will be used if an external mic is not
connected.
2
Connect your Mic and Mixer to the VE-5
Connect the VE-5 between your mic and mixer.
page 10
Mic
MIC IN jackXLR OUT jack
Mixer or Recorder
Typical connection for a mic
Connection when using the VE-5
Phantom power setting
If you’re using a condenser
mic that requires phantom
power, turn phantom
power on as described on
“Phantom Power Setting”
(p. 11).
Mic stand
You can attach the VE-5
to your mic stand.
Headphones
Connect stereo headphones
(sold separately) with a
stereo mini-plug to the
PHONES/LINE OUT jack.
page 10
When connecting via line output
If you want to connect the VE-5 via its line output to your mixer, connect a com-
mercially available Y-adaptor audio cable to the PHONES/LINE OUT jack.
Internal Mic
page 11 page 12
* Before you make connections,
make sure that the input gain or
volume of your mixer or recorder
is turned down. By turning on
devices in the wrong order, you
risk causing malfunction and/or
damage to speakers and other
devices.
