Bowflex PR3000 - Attach the Rear Lat Cross Bar

Assembly
Step 10: Attach the Rear Lat Cross Bar
Parts
• RearLatCrossBar(#25)
• UpperLatTowerAssembly(fromstep9)
Hardware
• (2)1/2”x51/4”HexHeadBolts(#14)
• (4)1/2”Washers(#4)
• (2)1/2”NylockNuts(#9)
Tools
• (2)AdjustableWrenches(notincluded)
10-1 Attach the Rear Lat Cross Bar to the Upper Lat Tower Assembly.
10-2 Install hardware, but do not tighten.
25
14
4
9
Assembly Manual
15
