10
NPLC: {0.02, 0.2, 1, 10, 100} Default: 10 PLC
Freq (Temp)
To configure the frequency and period measurements
Filter: 3 Hz, 20 Hz, 200 Hz
Gating time: 10ms, 100ms (default), 1s
Shift + Freq
(Temp)
To configure the temperature test
Probe type: two-wire test (default) or four-wire test
R0: resistance at 0 °C, default: 100 Ω
NPLC: {1, 10, 100} Default: 10 PLC
Unit: °C, °F, K,
Cont (diode)
Conduction (continuous) configuration
Test range: 1 kΩ
Test current: 1 mA
Buzzer: ON (default) or OFF
Door threshold: default 10 Ω, can be set separately
Shift + Cont
(diode)
Diode configuration
Test voltage range: 0~5V
Test current: 1 mA
Buzzer: ON (default) or OFF
CAP(MATH)
Capacitance measurement configuration
Range: Auto (default) {1nF, 10F, 100nF, 1uF, 10uF, 100uF, 1mF, 10mF}
Shift+
CAP(MATH)
Math zero calculation (NULL), you can set parameters
dB/dBm operation
smoothing
scal: Mx+b, Percent
Statistics, Limit
NULL (PrtScn)
Mathematical zeroing calculation, the calculated value is the current measured
data
Shift+NULL
(PrtScn)
Print the picture and save the current display interface
R/S
Run or Stop
Trigger
Single trigger
Menu
Menu Settings
Display: display settings
Acquire: trigger option
Utility: general function
