Step 3: Select the range.
Press Range and select the range. Auto range (Auto) can automatically select the appropriate range for
measurement based on the input signal. The auto range is adjusted upwards to 110% of the existing
range and down to 10% of the existing range.
3.3.9 Diode
This section describes how to configure the diode test from the front panel. The range and resolution
are fixed and the range is 10 VDC with 1 mA current source output.
Step 1: Configure the test leads as follows:
