26
The continuity measurement behavior is as follows:
Display the measured resistance and beeps (if the beeper is enabled).
Display measured resistance, no buzzer.
Display OPEN (ON), no buzzer.
3.3.11 Temperature test
This section describes how to configure 2-wire and 4-wire temperature measurements from the front
panel. Temperature measurements require a temperature transducer probe.
Step 1: Configure the test leads as follows:
2-wire temperature 4-wire temperature
Step 2: Press then press on the front panel. The following menu will appear. Please note
that Auto Zero is only available for 2-wire measurements.
