Bpt TH 400 - Personalizing Heating Temperature Levels; Enabling Heating Program and Setting Levels

GB
15
T3 is set at 20 °C and level T1 is set
at 16 °C, the value of T2 can only
be set between 16.1 °C and 19.9
°C. In order to achieve a value out-
side this range, e.g., higher than
19.9 °C, you must first change the
value of the adjacent level, e.g.,
increase the value of T3.
T3
T2
T1
ON
048121620
R
T
12
3
4
56
7
T3
T2
T1
ON
048121620
R
T
12
3
4
56
7
Fig. 35
Fig. 36
grammed interval, press the
button, figure 33.
6 - PERSONALIZING
TEMPERATURE LEVEL
VALUES FOR THE
HEATING PROGRAM
6.1 - Open the front panel on the
thermostat.
6.2 - Make sure that the heating
program bar is enabled, or ena-
ble it by means of the but-
ton, figure 34.
6.3 - Press button T, figure 35.
The temperature band for T1
appears on the display and the
value of the temperature assigned
to T1 (16 °C in the permanent
memory) is indicated instead of
the room temperature.
6.4 - Set the required temperatu-
re value for T1 by means of the
or button, figure 36.
6.5 - Press button T to confirm
the temperature value indicated on
the display and move on to the
next temperature level, figure 37.
Note. The value which can be assi-
gned to each T level is restricted by
the values of the levels immedia-
tely before and after it, i.e., if level
T3
T2
T1
ON
048121620
R
T
12
3
4
56
7
Fig. 34
T3
T2
T1
ON
048121620
R
T
12
3
4
56
7
Fig. 37
