Printing Labels 45

The STX L command switches the Printer from the system level to the label

formatting command. All command characters after STX L are interpreted as

Label Formatting Commands until terminated with E,X, or s. All label

formatting commands are terminated with 0D HEX.

CC Description Format

: Set cut by amount (4 digits)

The cutter function will perform a cutting

action after the number of labels specified

:nnnn

nnnn = 4 digits of labels printed

before cut. Default = 0001

A Set format attribute

An n = 1 - XOR

2 - Transparent

3 - Opaque

5 - Inverse

C Set column offset amount

Cnnnn nnnn = Inches/100

c Set cut by amount (2 digits)

cnn nn = 2 cut amount

D Set height and width dot size

h = Horiz. dot size; can be 1 or 2

v = Vert. dot size; can be 1,2, or 3

(0.005" steps) Default is “D22”

E Terminate field generation and print label

G Place data in global register

H Enter heat setting

(The amount of heat applied per dot row can

be used to help control print quality)

Hnn nn = 2 digits. 1 - 30

10 is nominal and default

Print contrast is relative to speed

M Mirror text/bar code Second transmission restores print

m Set metric mode

P Print speed

Pa a = single char.

Enter maximum speed for print cycle, 1

character

C 2.0 ips

D 2.5 ips

E 3.0 ips

F 3.5 ips

G 4.0 ips

H 4.5 ips

I 5.0 ips

J 5.5 ips

K 6.0 ips

L 6.5 ips

M 7.0 ips

N 7.5 ips

O 8.0 ips

P 8.5 ips

Q 9.0 ips

R 9.5 ips

S 10.0 ips

p Set label backup speed

pa a = single char. (C - I)

Q Enter quantity of labels to print

Qnnnn nnnn = quantity

R Set row offset amount

Rnnnn nnnn = row offset

r Recall stored label format

rnn...n nn...n label name of up

to 16 char. terminated by CR

S Slew speed

Sa a = single character

Sets maximum speed for label feeding. 1

digit.
