Branson 2100 - Page 178

ELECTRIC SYSTEM
KUKJE MACHINERY CO., LTD.
175
4) Turn Signal Light Switch Continuity When Setting Switch Knob OFF Position
1. Set the hazard switch knob to the OFF position.
2. Measure the resistance with an ohmmeter across the B2 terminal and L terminal, and across B2 terminal
and R terminal.
3. If infinity is not indicated, the combination switch is faulty.
B2 terminal –
L terminal
Resistance
(Switch knob at
OFF position)
B2 terminal –
R terminal
Infinity
5) Turn Signal Light Switch Continuity When Setting Switch Knob at 1 Position
1. Set the hazard switch knob to the 1 position.
2. Measure the resistance with an ohmmeter across the B2 terminal and R terminal.
3. If 0 Ω is not indicated, the combination switch is faulty.
B2 terminal –
R terminal
0 Ω
Resistance
(Switch knob at
1 position)
B2 terminal –
L terminal
Infinity
6) Turn Signal Light switch Continuity when Setting Switch Knob at Position
1. Set Measure the resistance with an ohmmeter across the B2 terminal and L terminal.
2. Measure the resistance with an ohmmeter across the B2 terminal and L terminal.
3. If 0 Ω is not indicated, the combination switch is faulty.
8. CHECKING DISASSEMBLING AND SERVICING
