8.3.5 Other Items used with the DCX A Power Supply
* When using a fan filter on a DCX A Power Supply, the maximum output power must be derated by 10%.
Table 8.12 Other Items used with the DCX A Power Supply
Product Description Part No.
Silicone grease For use with 40 kHz systems 101-053-002
Mylar Plastic Film Washers
(for 20 kHz systems)
Kit, 10 each (1/2 in. and 3/8 in.) 100-063-357
Kit, 150 each (1/2 in.) 100-063-471
Kit, 150 each (3/8 in.) 100-063-472
Mylar Plastic Film Washers
(for 30 kHz systems)
Kit, 10 each (3/8 in.) 100-063-632
Kit, 150 each (3/8 in) 100-063-712
Tool Kit
20 kHz (spanner wrench and 10 pc
washer kit)
101-063-208R
30 kHz (spanner wrench and 10 pc
washer kit)
101-063-636R
40 kHz (spanner wrench and silicone
grease)
101-063-176R
Spanner wrench
20 kHz 101-118-039
30 kHz 201-118-033
40 kHz 201-118-024
Studs
1/2-20 x 1-1/4 (titanium horns) 100-098-370
1/2-20 x 1-1/2 (aluminum horns, 20
kHz boosters)
100-098-123
3/8-24 x 1 (30 kHz titanium horns and
boosters)
100-298-170
M-8 x 1.25 (40 kHz horns and boosters) 100-098-790
Fan Filter*
For small size units (400 W, 750 W, and
800 W)
101-063-936
For medium size units (1250 W, and
1500 W)
101-063-935
For large size units (
2500 W, and 4000 W) 101-063-934
Connector Block Detachable connector block 200-029-1108
Top Mounting Plate Top mounting plate for vertical units. 100-079-462
Bottom Mounting Plate
Bottom mounting plate for vertical
units.
100-079-463
