5.3.9 Digital Output Functions
Table 5.12 Digital Output Functions
Function Description
ACT-Actuator
Home
Indicates that a ULS input has been received.
ACT-Afterburst
Delay
Indicates if the weld cycle is in the Afterburst Delay state.
ACT-Afterburst
Time
Indicates if the weld cycle is in the Afterburst state.
ACT-End of Hold
Time
Indicates the system has reached the end of Hold since the cycle
started.
ACT-Holdtime Indicates if the weld cycle is in the Hold Time state.
RF-Select A-D
Output to select stacks 1 to 4 or a binary coded value (bit 0-3) to
select RF relay.
STD-Amp1
Amp2
If output is 0 V, indicates the amplitude setting is Amplitude 1. If
output is 24 V, indicates the amplitude setting is Amplitude 2.
STD-Confirm
Preset Change
Output will go active when a preset has been recalled.
STD-Custom
Alarm
Indicates a Custom Alarm has occurred. This function is user defined.
STD-Cycle Okay
Output will go inactive with cycle start input, and will go high at the
end of the cycle if no alarms occurred.
STD-Cycle Start
Out
Indicates start signal is active. It will stay active through weld time
and hold time.
STD-General
Alarm
Indicates an alarm occurred. This function is user configurable.
STD-Minus
Energy Limit
Alarm
Indicates the weld did not reach the minimum energy set.
STD-Minus
Time Limit
Alarm
Indicates the weld time has not reached the minimum time set.
STD-Minus
Peakpower
Limit Alarm
Indicates the weld has not reached the minimum peak power set.
STD-Overload
Alarm
Indicates an overload alarm has occurred.
STD-Plus
Energy Limit
Alarm
Indicates the weld has exceeded the maximum energy set.
