100-412-197 REV. 07 61
STD-Plus Time
Limit Alarm
Indicates the weld time did exceed the maximum time set.
STD-Plus
Peakpower
Limit Alarm
Indicates the weld has exceeded the maximum peak power set.
STD-Ready
If active, indicates the system is ready to start a weld cycle, enter
test mode, or start a horn scan. If inactive, it indicates the system is
already cycling, in test mode, performing a horn scan, or has a reset-
required alarm.
STD-Seek/Scan
Out
Indicates either a seek or a horn scan is in progress.
STD-Sonics
Active
Indicates sonics are active.
STD-Start
Signal Release
If output is active, it indicates the start signal can be removed, If
output is inactive, it indicates start signal is either inactive or that it
cannot yet be removed.
STD-Status
To be used to drive an external beeper. Single 0.5 second beeps will
occur when trigger is received. Three Beeps indicate an alarm
occurred (e.g. overload alarm). Beeps 0.5 seconds on, 0.5 seconds
off long are in between each beep.
STD-Weldcycle
Complete
Indicates if a weld cycle is no longer in process.
Table 5.12 Digital Output Functions
Function Description
