Figure 5.12 Assembling the Acoustic Stack

Acoustic Stack Description

Table 5.19 Acoustic Stack Description

Item Description

1 Converter

2 Booster

3 Spanner (provided)

4 Horn

5 See stack assembly procedure

Vise Jaw protectors (aluminum or soft

metal)

7 Vise
