5.3.4 Mounting Considerations

In addition to the considerations mentioned above, the LCD’s viewing angle should be

taken into account when selecting a location for your DCX A Power Supply. The LCD is

designed to be viewed from the top. Please refer to Figure 5.5 LCD Viewing Angle below

when selecting a location for your DCX A Power Supply.

Figure 5.5 LCD Viewing Angle

NOTICE

Optimal viewing angle is 25° above the normal to the display

(indicated by 0°).
