Branson DCX A Series - Table 5.20 Stack Torque Values; Table 5.21 Tools

100-412-197 REV. 07 75
Stack Torque Values
Tools
Table 5.20 Stack Torque Values
Frequency Torque
20 kHz 220 in·lb (24.85 N·m)
30 kHz 185 in·lb (21 N·m)
40 kHz 95 in·lb (10.73 N·m)
Table 5.21 Tools
Tool EDP Number
20 kHz, and 30 kHz Torque Wrench Kit 101-063-787
40 kHz Torque Wrench 101-063-618
20 kHz Spanner Wrench 101-118-039
30 kHz Spanner Wrench 201-118-033
40 kHz Spanner Wrench 201-118-024
Silicone Grease 101-053-002
Mylar Plastic Film Washers (20 kHz) 100-063-357
Mylar Plastic Film Washers (30 kHz) 100-063-632
