23
4.3.9.4 DEW POINT
- The dew point is the temperature below which the water vapor in air at constant barometric
pressure condenses into liquid water at the same rate at which it evaporates. The condensed
water is called dew when it forms on a solid surface.
- The dew point temperature is determined by the temperature & humidity data from wireless
7-in-1 sensor.
4.3.10 INDOOR / CHANNELS TEMPERATURE & HUMIDITY
This section can show reading and status of the indoor, optional hygro-thermo sensor(s) and
water leak sensor(s).
1. Channel (CH) number
2. Low battery indicator for CH sensor
3. Sensor signal strength icon
4. Indoor / CH sensor temperature trend
5. Water leak sensor status (for optional sensors)
6. Auto loop icon
7. Indoor / CH sensor temperature reading
8. Floating pool sensor icon
9. Soil moisture sensor icon
10. Indoor / CH sensor humidity reading
11. Indoor / CH sensor humidity trend
4.3.10.1 INDOOR TEMPERATURE & HUMIDITY
The indoor reading is default mode of the console,
which shows the temperature and humidity reading of
indoor.
You can add up to 7 additional Thermo-Hygrometer
sensor (optional, refer to section 3.2). Press the [ CH ]
key to switch between indoor and Channels 1 to 7.
For auto-scroll function, just press and hold the [ CH ] key for 3 seconds and the icon will
appear next to CH. The console will scroll the readings of all the sensors every 3 seconds.
This mode shown below information:
- Channel number of the current sensor
- Temperature and humidity reading of this sensor
- Signal strength of this sensor.
- Sensor type icon (for water pool or soil moisture sensor)
4.3.11 WATER LEAK (OPTIONAL LEAK SENSOR)
You can add up to 7 additional Water Leak sensors (optional, refer
to section 3.2)
The channel number(s) of the corresponding water leak sensor(s)
added to the console will be shown with the NO LEAKING icon.
When water leaking is detected, the channel number of the sensor
