Function
Location
Zone Lights or Status
Light flash frequency
Buzzer alert
Interval
System off
(Not powered)
Status Light
Off
Off
Configuration Tool
in connected state
Status Light
Green /
1 time per second
Off
Power cycle
required after new
sensor connected
Status Light
Alternating between
Red and Green /
0.5 second each
Constant for
0.5 second,
repeated in 5
seconds
System power on
Self-Test
(After applying
power supply)
All Zone Lights
Constant for 1 second
Constant for
1 second
Status Light
Red / Constant for
5 seconds
System Standby
(After Self-Test)
Status Light
Red / Constant
Off
At point of system
activation and no
object detection
(When Activation
Input is applied)
Status Light
Green / Constant
0.2 second
on, 0.2
second off,
0.2 second
on,
Off
System Active and
no object detection
(After Activation
Input is applied)
Status Light
Green / Constant
Off
Detection in Zone 5
(Furthest Detection
Zone)
Green Zone Light
Constant
1.5 times per
second
Detection in Zone 4
Green & Light Green Zone
Lights
Constant
2 times per
second
Detection in Zone 3
Green & Light Green & Yellow
Zone Lights
Constant
2.5 times per
second
Detection in Zone 2
Green & Light Green & Yellow
& Orange Zone Lights
Constant
3 times per
second
Detection in Zone 1
(Closest Detection
Zone)
Green & Light Green & Yellow
and Orange & Red Zone Lights
Constant
Constant
System / Sensor
Error occurred with
System Active
All Zone Lights
Constant for 5 seconds
Constant for
5 seconds
Status Light
Red / 1 time per second
System / Sensor
Error with System
Active
Status Light
Red / 1 time per second
0.5 second,
repeated in
5 seconds
System / Sensor
Error with System
Standby
Status Light
Red / 1 time per second
Off
The BS-8100 allows the settings to be configured for: Detection length, detection width, zones
length, blind length, blind width and blind zones, trigger output length and buzzer starting
zone. Refer to section “4 Configuring the BS-8100”.
