Brigade Backsense BS-8100 - Specifications

37
6 Specifications
Operation Characteristics
Model name
BS-8100
Metres
Feet
Detection length
3 – 60 (10
[1]
)
10 – 197 (33
[1]
)
Each Detection Zone length
0.6 – 56 (2
[1]
)
2 – 184 (7
[1]
)
Detection width
2 – 16 (7
[1]
)
7 – 52 (23
[1]
)
Nominal tolerance
±0.25
±1
[2]
Distance resolution
≥ 0.25m
[2]
1ft
[2]
Radar beam angle
Horizontal 140° out to the maximum designated width
Vertical 16° (Symmetrically perpendicular to sensor front
surface)
System Reaction Time
≤ 0.1s
[2]
Power on to standby
≤ 6s
System standby to active
≤ 0.6s
[1] Default setting
[2] Limitations apply, see section “1.2 Object Detection Capability”
Communication between Sensor and Display
Physical layer
CAN bus 2.0A Base Frame Format
Protocol layer
Proprietary Protocol (cannot be integrated or networked with
other systems on vehicles)
Max. cable length between
display and sensor
30m (98ft)
Sensor Specifications
Transmitter
Frequency Modulated Continuous Wave (FMCW)
Frequency and bandwidth
77GHz
Dimensions
160mm x 100mm x 40mm
Connector
Manufacturer Deutsch
Part Number DT06-4S-CE06 (female)
Cable length
1.0m / 3ft 3in
Weight
0.34kg (including pigtail cable)
Operating temperature
-40°C to +85°C
IP protection
IP69K (protected from dust and strong water jets / immersion
into water) protective housing
Vibration
8.3G
Shock
51G all three axes
Mounting
Four (5.2mm) diameter holes on 147mm horizontal centres,
and 43.5mm vertical centres.
Unit is supplied with M5x30mm screws and M5 polymer
locknuts for mounting purposes. Recommended torque is
5.6Nm (50 in/lbs approx.)
Bracket
Optional, adjustable for vertical angle
