Display Specification
Zone Lights
Large and high ambient light visibility
Luminance >300cd/m
2
Buzzer
Buzzer volume control wheel
Sound pressure level adjustable 70dB(A) to 90dB(A) (at 1m
distance), frequency 2800±300Hz
Programming interface
Mini USB socket
Dimensions (all in mm)
101 x 70 x 29 (with bracket 71)
Connector
Manufacturer Deutsch
Part Number DT04-4P-CE02
Cable length
1.5m / 5ft
Weight
0.3kg (including pigtail cable)
Operating temperature
-40°C to +85°C
IP Protection
IP30 (not water protected)
Vibration
8.3G
Shock
100G all three axes
Mounting
Via bracket adjustable in all direction approximate 30°
Base supplied with self-adhesive tape. Possibility to fix base
with additional screws (not supplied)
Removable bracket for flush mount
Electrical Specification
Input voltage
12Vdc / 24Vdc
Input current
typ. 0.52A at 12Vdc / typ. 0.32A at 24Vdc / max. <0.8A
Fuse
3A, automotive (regular size) blade fuse type, located on red
power supply cable
Polarity
Negative ground
Vehicle connection
System supplies: positive & negative, activation input, and
trigger output
4 single cables exiting at the back of the connector on the
end of the display cable
Activation Input:
Rating 0Vdc to 32Vdc
System active above 9Vdc, inactive below 7Vdc
Trigger Output
Active State: switched to ground up to 0.5A
Inactive State: High impedance (> 1 MOhm)
Voltage protection
ISO 16750 (over and reverse voltage protection)
