Brixton BX125 - Vehicle Body Inspection and Maintenance

32
Vehicle body Inspection and Maintenance
Front and Rear Hydraulic Brakes (CBS)
S/N
Name
S/N
Name
1
Disc brake assembly (CBS)
1-13
Rear disc brake push rod
1-1
Front disc brake hose 2
1-14
Rear disc brake hose 2
1-2
Disc brake CBS dispenser
1-15
Bolt M8×20
1-3
Bolt M6×45
1-16
Rear disc brake connecting
plate
1-4
Front disc brake hose 1
1-17
Rear disc brake caliper
assembly
1-5
Front disc brake upper pump
1-18
Front disc brake lower pump
assembly
1-6
Bolt M6×25
1-19
Front disc brake support
1-7
Front disc brake handle
1-20
Bolt M10×35
1-8
Disc brake half-overlay
1-21
Front disc brake pad
1-9
Rear disc brake hose 1
1-22
Rear disc brake pad
1-10
Rear disc brake switch
1-23
Bolt M6×16
1-11
Rear disc brake upper pump assembly
1-24
Rear disc brake support
1-12
Bolt M6×25
