Brixton BX125 - Front Wheel

43
3.2.7 Soft front shock absorber
 Inadequate fluid in the shock absorber
 Infirm shock absorber spring
 Low tire pressure
3.2.8 Too hard front shock absorber
 Inappropriate fluid weight
 Blocked shock absorber fluid channel
3.3 Front wheel
3.3.1 Removal
Support the vehicle bottom to make the front wheel lifted
Unscrew the locknut of front axle
Remove the front wheel shaft
Remove the front wheel
Remove the oil seal and bearing of oil seal remover and
shaft bearing replacer.
3.3.2 Inspection
3.3.2.1 Inspection of wheel shaft bending
Place the wheel shaft onto a V-shaped base, and the
measure eccentricity with a micrometer gauge.
Service limit: replacing in case of exceeding 0. 2mm.
3.3.2.2 Inspection of wheel disk
wobbling
Service limit:
Longitudinal direction: replacing in case of
exceeding 2. 0mm
Horizontal direction: replacing in case of
exceeding 2. 0mm
