3.3.2.3 Inspection of front wheel bearing
Remove the middle lining of front wheel and the oil
seal.
Inspect rotation of bearing.
If the bearing is found not to rotate, it indicates that
the bearing is worn or loosened, and it shall be
replaced with new bearing.
3.3.3 Bearing replacement
After remove front wheel, front wheel shaft and front
wheel lining, oil seal removing appliance and bearing
removing appliance must be used to remove the lower
oil seal and bearing respectively.
Note: the removed bearing must be replaced with
new bearing.
During installation, apply the lubricating grease onto
the bearing.
And then, use the bearing mounting tool to press the bearing.
