* Attentions
• The bearing must be pressed in a
parallel manner.
• The bearing oil seal shall be pressed
towards outside.
3.3.4 Installation
Apply lubricating grease for the oil seal at front wheel.
Apply lubricating grease for the gear position and movable position of speedometer.
Install the brake disc after the involution of the gear housing assembly of speedometer
Attentions
• The odometer gear housing
component will deform if the
component is not aligned to the locked
front wheel shaft.
• Rotate the wheel after mounting the
axle to check whether the drive axle of
speedometer to rotate.
Install the front axle and lock it
Torque value
Front axle: 75-85N·m
3.4 Steering handlebar
