Brixton BX125 - Inspection and Maintenance of Engine

79
Inspection and Maintenance of Engine
List of Engine Fastener Torque Value
S/N
Inspection Items
Diameter of
Thread
Required Moment of
Force (N.m)
1
Positioning piece bolt torque (five-star
plate)
M6
10～15
2
Positioner mounting bolt torque
(Positioning wheel)
M6
10～15
3
Oil filter lock nut torque
M16
45～55
4
Clutch lock nut torque
M16
45～55
5
Oil strainer tightening torque
M36
20～28
6
Cylinder head nut torque
M8
25～35
7
Starting clutch bolt
M8
25～32
8
Valve adjustment nut torque
M6
13～17
9
Spark plug torque
M12
15～20
10
Conductor press plate bolt torque
M6
8～12
11
Box closing screw
M6
10～15
12
Oil pump mounting screw
M6
6～10
13
Rotor cover screw
M5
4～6
14
Clutch cover bolt
M6
10～15
15
Bearing thrust bolt torque
M6
8～12
16
Sprocket bolt torque
M6
10～15
17
Gear switch screw
M4
1～3
18
Magneto stator bolt
M6
5～8
19
Trigger coil bolt
M5
4～6
20
Magneto rotator fixing bolt torque
M10
40～50
21
Magneto cover bolt
M6
10～15
22
Starter motor bolt
M6
8～12
23
Cylinder block side bolt
M6
8～12
24
Intake manifold bolt torque
M6
8～12
25
Gear chamber cover bolt
6
8～12
26
Cylinder head cover bolt
M6
8～12
27
Left trademark cover screw
M6
8～12
28
Left trademark cover screw
M6
8～12
29
Clutch cable bracket bolt torque
M6
8～12
30
Timing driven sprocket screw
M6
10～15
31
Tensioning strip bolt
M8
10～15
32
Tensioner bolt
M6
8～12
