47
1
Decorative buckle
2-10
Steering stem upper
washer
2
Steering stem assembly
2-11
Steering stem cover nut
2-1
Steering handle clamp
3
Headlight bracket
2-2
Steering handle holder
3-1
Screw M6×16
2-3
Steering handle holder
damped adhesive
4
Front left shock absorber
2-4
Upper steering
4-1
Front shock absorber boot
2-5
Hexagon socket cap head
screws M8×30
4-2
Front shock absorber seal
2-6
Holder washer
5
Speedometer cable clip
2-7
Nut M8
6
Bolt M6×12
2-8
Steering stem
7
Side reflector
2-9
Steering bearing
8
Front right shock
absorber
3.5.1 Removal
Remove the front fender.
Remove the front wheel.
Remove the brake hose and speedometer cable.
Remove the front shock absorber.
Remove the steering fixing nut.
Remove the steering handle.
Tools:
Steering handle fixing screw wrench.
Fixing nut wrench.
3.5.3 Installation
Tools:
Fixing nut wrench.
Turn the front fork left and right to confirm its smoothness without any looseness.
Steps:
Install the steering handle.
Install the front shock absorber.
Install the front wheel.
