G720-Install-IG101 Installation Guide Brocade
®
G720 Switch Hardware Installation Guide
Data Port Specifications (Fibre Channel)
Model Name Port Numbers Media Type Description
Brocade G720
Switch
Ports 0–47, 48, 50, 52,
54, 56, 58, 60, and 62
56 SFP+ optical ports, up to 64Gb/s,
supporting 8, 10, 16, 32, or 64Gb/s
Can be an F_Port, N_Port, E_Port, or EX_Port.
Mini-USB Pinout
Pin Number Mini-USB UART
1 Pull down with 100K resistor
2 UART1_RXD Receiver data
3 UART1_TXD Transmit data
4 GND
5 GND
6 GND
7 GND
NOTE
These specifications are for connectors on Brocade platforms only.
Serial Port Specifications (Protocol)
Parameter Value
Baud 9600
Data bits 8
Parity None
Flow control None
Stop bits 1
G720-Install-IG101
73
Broadcom
