RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for
1+1 redundancy with one 500W AC power supply included.
FIGURE 22 Brocade NetIron CES Series 2024F device
1 Four combination 10/100/1000 MbE RJ45 ports with support for optional 10Gbe XFP ports
2 Twenty-four 100/1000 MbE SFP ports
Brocade NetIron CES Series 2048C
Brocade NetIron CES Series 2048C (Copper) switch has forty-eight 10/100/1000 MbE RJ45 ports plus
four combination 100/ 1000 MbE SFP ports, one DB9 serial management interface port labeled
Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray,
and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included.
FIGURE 23 Brocade NetIron CES Series 2048C device
1
Four combination 100/1000 MbE SFP ports
2 Forty-eight 10/100/1000 MbE RJ45 ports
Brocade NetIron CES Series 2048CX
Brocade NetIron CES Series 2048CX (Copper) has forty-eight 10/100/1000 MbE RJ45 ports plus two
10 GbE XFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE
RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for
1+1 redundancy with one 500W AC power supply included.
Brocade NetIron CES Series 2048C
24 Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide
53-1003823-01
