FIGURE 28 Brocade NetIron CER Series 2024F device
1 Four combination 10/100/1000 MbE RJ45 ports with support for optional 10Gbe XFP ports
2 Twenty-four 100/1000 MbE SFP ports.
Brocade NetIron CER Series 2048C
Brocade NetIron CER Series 2048C (Copper) router has forty-eight 10/100/1000 MbE RJ45 ports plus
four combination 100/ 1000 MbE SFP ports, one DB9 serial management interface port labeled
Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and
two AC power supply bays for 1+1 redundancy with one 500W AC power supply included.
Brocade NetIron CER Series-RT 2048C (Copper) router has more memory to support 1.5M routes,
forty-eight 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one DB9
serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band
management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy
with one 500W AC power supply included.
FIGURE 29 Brocade NetIron CER Series 2048C device
1
Four combination 100/1000 MbE SFP ports
2 Forty-eight 10/100/1000 MbE RJ45 ports
Brocade NetIron CER Series 2048CX
Brocade NetIron CER Series 2048CX (Copper) has forty-eight 10/100/1000 MbE RJ45 ports plus two
10 GbE XFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE
RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for
1+1 redundancy with one 500W AC power supply included.
Brocade NetIron CER Series-RT 2048CX (Copper) has more memory to support 1.5M routes, forty-
eight 10/100/1000 MbE RJ45 ports plus two 10 GbE XFP ports, one DB9 serial management interface
Brocade NetIron CER Series 2048C
Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide 27
53-1003823-01
