LEDs for power for the 2048 models (Continued)TABLE 10
LED Position State Meaning
Green Power supply has DC power, is enabled, and has
good output.
Green blinking Power supply has input power, but DC output is
not enabled.
The software regularly polls the hardware for power status information. You can display the status
information from any management session. In addition, the software automatically generates a Syslog
message and SNMP trap if a status change occurs.
PC or terminal attachment
To assign an IP address, you must have access to the Command Line Interface (CLI). The CLI is a text-
based interface that can be accessed through a direct serial connection to the device and through
Telnet connections.
You need to assign an IP address using the CLI. You can access the CLI by attaching a serial cable to
the Console port. After you assign an IP address, you can access the system through Telnet or Brocade
Network Advisor.
Attaching a PC or terminal
Follow the steps given below to attach a management station using the serial port.
1. Connect a PC or terminal to the serial port of the system using a straight-through cable. The serial
port has a male DB-9 connector.
NOTE
You need to run a terminal emulation program on the PC.
2. Open the terminal emulation program and set the session parameters as follows:
• Baud: 9600 bps
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow control: None
When you establish the serial connection to the system, press Enter to display the CLI prompt in the
terminal emulation window. For example:
device>
If you see this of these prompt, you are now connected to the system and can proceed to Attaching a
PC or terminal.
You can customize the prompt by changing the system name. For more information, refer to the
Brocade Multi-Service IronWare Configuration Guide.
If you do not see one of these prompts, follow the instructions given below.
PC or terminal attachment
Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide 61
53-1003823-01
