MSA-compliant Optics for the 10 GbE Ethernet interface module TABLE 6
Part number Description
Devices with up to two 10GbE ports (XFP)
10G-XFP-SR 850nm serial pluggable XFP optic, target range 300m over multi-mode fiber
10G-XFP-LR 1310nm serial pluggable XFP optic for up to 10km over single-mode fiber
10G-XFP-ER 1550nm serial pluggable XFP optic for up to 40km over single-mode fiber
10G-XFP-ZR 1550nm serial pluggable XFP optic for up to 80km over single-mode fiber
10G-XFP-ZRD 10GBase-ZR DWDM, XFP optic, 80km, 1530.33 to 1561.42
10G-XFP-CX4 10-Base-CX4, XFP transceiver, 15km, CX connector
Devices with up to four 10GbE ports (SFP+)
10G-SFPlus-SR
10G-SFPlus-LR
10G-SFPlus-ZR
10G-SFPlus-ZRD
Port regions
Ports on the devices are grouped into regions. For a few features, such as port monitoring and unknown
unicast configurations, you will need to know the region to which a port belongs. However, for most
features, a port’s region does not affect configuration or operation of the feature. If a port’s region does
affect configuration or operation of a feature, it is noted and described in the appropriate feature section
of this guide.
Brocade NetIron CES Series 2024 and CER 2024 devices with 24 ports have 2 optional 10-GbE ports:
Ports 1/1 - 1/24
Port 2/1 (optional 10-GbE uplink port)
Port 2/2 (optional 10-GbE uplink port)
Port 2/3 (optional 10-GbE uplink port)
Port 2/4 (optional 10-GbE uplink port)
Brocade NetIron CES Series 2048 and Brocade NetIron CER Series 2048 devices with 48 ports:
Ports 1/1 -1/24
Ports 1/25 - 1/48
Port 2/1 (10-GbE uplink port on Brocade NetIron CES Series 2048CX, Brocade NetIron CES Series
2048FX, Brocade NetIron CER Series 2048CX, and Brocade NetIron CER Series 2048FX models
only)
Port 2/2 (10-GbE uplink port on Brocade NetIron CES Series 2048CX, Brocade NetIron CES Series
2048FX, Brocade NetIron CER Series 2048CX, and Brocade NetIron CER Series 2048FX models
only)
Port regions
Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide 33
53-1003823-01
