1-6
Forward gear ratios and speeds: Reverse gear ratios and speeds:
GEAR RATIO SPEED GEAR RATIO SPEED
1
st
8.93 2.1 mph (3.4 km/h) 1
st
8.93 2.7 mph (4.3 km/h)
2
nd
4.63 4.0 mph (6.4 km/h) 2
nd
4.63 6.3 mph (10.1 km/h)
3
rd
1.70 10.5 mph (16.9 km/h) 3
rd
1.70 15 mph (25.4 km/h)
4
th
3.75 4.9 mph (7.9 km/h) 4
th
3.75 4.9 mph (7.9 km/h)
5
th
1.94 9.2 mph (14.8 km/h) 5
th
1.94 9.2 mph (14.8 km/h)
6
th
0.71 23.6 mph (38 km/h) 6
th
0.71 23.6 mph (38 km/h)
Front Axle:
Standard:
Planetary driving-steering axle with 19.333 to 1 ratio. Front axle is rigid-mounted. Axle has
a 30% limited-slip differential.
Rear Axle:
Standard:
Dana Corporation planetary driving-steering axle with 19.333 to 1 ratio. Rear axle is rigid
mounted. Axle has a 30% limited-slip differential.
Brakes:
Standard:
Service brakes are 4-wheel hydraulic, internal wet-disc brakes. System includes two, 0.5-
gallon (1.9 L) accumulators, unloading valve, and brake malfunction warning light. Parking
brake is internal wet-disc, spring applied and hydraulically released, and integral to the rear
axle.
Steering:
Standard:
Hydraulic steering unit with a 4.0-inch (10.1 cm) cylinder attached to each axle. Allows
limited steering when engine is not running. Selecting front-wheel steering, 4-wheel steering,
or crab steering is done through electronic push button operator interface in the operator
compartment. Electronic sensors and control module automatically sense when the steering
is centered upon the selection of a new mode. Steering wheel and electronically-controlled
selector valve, control 3-mode steering.
Tires:
Standard:
17.5 x 25, 20-ply rating, mud lug
Optional Tires:
Spare Wheel and Tire:
Standard Size: Extra wheel with 17.5 x 25, 20-ply rating tire mounted, ready for service.
Order left hand or right hand. Net Weight: 530 pounds (240 kg)
Chassis:
Standard:
Cargo Deck:
Total Deck Area: 74 square feet (6.94m
²). Front deck: 102” (2.6 m) X 57.8” (1.5 m), RH
side deck 198.3” (5.04 m) X 32” (.81 m). A maximum of 25,000 pounds (11,340 kg) may
be carried on the deck when centered over or between axles. Five stake pockets are
provided along edges of deck for 1-inch (25mm) pipe stakes. Stakes furnished. Cargo
decks have skid resistant coating.
Headlight and Taillight Grilles:
Steel protective grilles for headlights and taillights. Easily removable for replacement .
