1-7
Outriggers:
Four hydraulic out-and-down outriggers of box-beam construction. Independent controls
for each outrigger. Hydraulic cylinders are equipped with direct-connected holding
valves. Pad dimensions: 11.5 inches (29cm) x 11.5 inches (29cm).
Pulling Eyes:
Two heavy duty lugs on front bumper provide for attachment of hook block so main winch
line can be used for pulling loads at or near floor level. Also for anchoring tag lines from
load on hook. Two heavy duty eyes on rear bumper allow dragging or towing a load.
Tie Downs:
Pulling eyes also provide tie down locations for transporting crane by truck or cargo
container.
Accessory Storage Box:
Consists of a hinged rear deck plate cover, and front box for carrying downhaul weight
and other items.Storage box is 13.88" (35cm) deep x 40.3" (102.4 cm) long x 18" (45.7
m) wide.
Sheave Block Storage Box:
Recessed area in front deck for stowing sheave block. Sheave block is stored on the
side, using eye bolt for easy lifting and lowering into storage box. Includes pin assembly
for securing sheave block.
Lifting Rings:
Consists of four rings, one at each corner of the load deck, so sling can be attached for
lifting crane. Rings hang below deck surface when not in use.
Engine Hood:
Side door and removeable side panels allow improved access to engine with boom
centered over the front of machine. Engine fluid levels can be checked without starting
engine and swinging boom.
Chassis Options and Accessories:
Auxiliary Winch:
Optional planetary gear winch, mounted on front outrigger bumper, with a single-lever
control in the operator compartment. Hydraulic powered to provide bare drum line pull of
15,000 lbs (6800 kg) and 40 ft/min (9 m/min) line speed on the fourth layer. Winch drum
is 4.75 inches (12 cm) diameter by 9 inches (23 cm) long. Includes 125 feet (38.1 m) of
9/16 inch (14 mm) diameter 6x36 EIP-RRL-IWRC wire rope, minimum breaking force
33,600 pounds (150 kN). Also includes 10,000 lb (4500 kg) eye hook. A pintle hook is
recommended for two-parting the line with a sheave block (pintle hook and sheave block
not included). Winch is mounted to heavy-duty bracket with hook storage feature. Net
weight: 580 pounds (265 kg)
Pintle Hook - Rear:
T-60-AOL Holland pintle hook mounted on rear frame member, provides capacity for
6,000 pound (2700kg) tongue weight and 30,000 pound (13600kg) trailer weight. Net
Weight: 15 pounds (7kg)
Pintle Hook - Front:
T-60-AOL Holland pintle hook mounted on front frame member, provides same capacity
as rear pintle hook. Net Weight: 15 pounds(7kg)
Rearview Mirrors:
One right-hand and one left-hand mirror, 6" (152mm) wide x 16" (406mm) high, mounted
on deck stakes. Pivot out of way when contacted by obstacle at side of deck. Net
Weight: 12 pounds (5kg)
