Brother 1034D Handbook

34
TABLE OF
CONTENTS
Chapter
1
Chapter
2
Chapter
3
Chapter
4
Chapter
5
Chapter
6
Chapter
7
Chapter
8
Chapter
9
Chapter
10
Chapter
11
Chapter
12
Chapter
13
Chapter
14
Chapter
15
Chapter
16
Chapter
17
Chapter
18
Chaining-off
• After test-sewing, continue to depress the foot
controller slightly and chain off 4 inches. The
threads will entwine themselves into a chain
automatically.
NOTE:
If the thread tension is not correctly balanced, the
chaining-off result will be uneven.
If this happens, pull the threads slightly. Check the
threading order and adjust the thread tension to
create an even chain. (See page 25.)
Cadeneta
• Después de la costura de prueba, siga apretando
el pedal y haga una cadeneta de unos 10 cm. Los
hilos van a engancharse automáticamente en
forma de cadena.
NOTA:
Si la tensión de los hilos no queda bien ajustada, la
cadeneta resultará desigual.
En este caso, tire para sacar un poco los hilos.
Compruebe el orden de enhebrado y ajuste la ten-
sión del hilo para crear una cadeneta uniforme.
(Vea la página 26.)

Brother 1034D Specifications

General

Type	Serger
Number of Threads	3 or 4
Stitch Length	1.0mm to 4.0mm
Differential Feed	Yes
Differential Feed Ratio	0.7 to 2.0
Maximum Sewing Speed	1, 300 stitches per minute
Color-Coded Threading	Yes
Adjustable Stitch Width	Yes
Free Arm	Yes
Thread Tension	Adjustable
Presser Foot Lifter	Yes
Built-in Thread Cutter	Yes
Free Arm Capability	Yes
Power Requirements	120V, 60Hz
Stitch Types	rolled hem
Stitch Width	5.0mm - 7.0mm (overlock), 2.0mm (rolled hem)
Needle	Standard sewing machine needles (size 11 or 14)
Included Accessories	gathering foot
