Brother 1034D Handbook

36
TABLE OF
CONTENTS
Chapter
1
Chapter
2
Chapter
3
Chapter
4
Chapter
5
Chapter
6
Chapter
7
Chapter
8
Chapter
9
Chapter
10
Chapter
11
Chapter
12
Chapter
13
Chapter
14
Chapter
15
Chapter
16
Chapter
17
Chapter
18
To remove work
• When the seam is finished, keep the machine
running at a low speed to obtain chaining-off.
Then cut the stitches 5 cm (2 inches) from the
work. If feeding for chaining-off is not enough, pull
the thread gently.
If threads break during
sewing
• Remove the material and re-thread in the correct
order. Upperlooper, Lowerlooper, right needle
and then the left needle. Replace the material
under the presser foot and sew 3-5 cm (1-1/8 to
2 inches) over the previous stitches.
CAUTION
Do not leave straight pins in the fabric when
sewing as they will damage the needles and
knives.
Para retirar el trabajo
• Una vez terminada la costura, siga cosiendo a
baja velocidad para formar una cadeneta. Luego,
corte las puntadas a unos 5 cm del trabajo. Si la
alimentación no resulta suficiente como para
crear una cadeneta, tire suavemente del hilo.
Si el hilo se rompe al
coser
• Quite el tejido y vuelva a enhebrar en el orden
correcto. Ancora superior, áncora inferior, aguja
derecha y luego aguja izquierda.
PRECAUCION
Nunca deje alfileres en el tejido al coser ya
que podrían romper las agujas y cuchillas.

Brother 1034D Specifications

General

Type	Serger
Number of Threads	3 or 4
Stitch Length	1.0mm to 4.0mm
Differential Feed	Yes
Differential Feed Ratio	0.7 to 2.0
Maximum Sewing Speed	1, 300 stitches per minute
Color-Coded Threading	Yes
Adjustable Stitch Width	Yes
Free Arm	Yes
Thread Tension	Adjustable
Presser Foot Lifter	Yes
Built-in Thread Cutter	Yes
Free Arm Capability	Yes
Power Requirements	120V, 60Hz
Stitch Types	rolled hem
Stitch Width	5.0mm - 7.0mm (overlock), 2.0mm (rolled hem)
Needle	Standard sewing machine needles (size 11 or 14)
Included Accessories	gathering foot
