85
BAS-311E.311EL.326E.326EL
Chapter 6 Power supply and electrical parts adjustment
■ DIP switch D
D-1
D-2
D-3
D-4
D-5
D-6
D-7
D-8
When ON
The first two stitches at the sewing start will be sewn at low speed (approx. 260 spm).
The last two stitches at the sewing end will be sewn at low speed (approx. 260 spm).
----------------
The last two stitches at the sewing end will be sewn at low speed (approx. 700 spm).
----------------
Slow-speed sewing at the sewing start will be canceled.
When the upper shaft is stopped, the motor will change direction and the needle bar will return to the
vicinity of the needle up stop position.
During an emergency stop, the thread is trimmed and the needle bar stops in the raised position.
SW No.
