Brother DCP-L2541DW Service Manual

5-19
Confidential
1.3.11 Display LAN connection status (function code: 33)
<Function>
This function is used to check the connection status of the wired LAN.
<Operating Procedure>
LCD LAN connection status
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected
For models without keypad
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 33" on the LCD, and
press the [OK] key. One of the following
items is displayed on the LCD
depending on the wired LAN connection
of the machine.
(2) When the [Stop] key is pressed, the
machine returns to the initial state of
maintenance mode.
For models with keypad
(1) Press the [3] key twice in the initial state
of maintenance mode. One of the
following items is displayed on the LCD
depending on the wired LAN connection
of the machine.
(2) When the [X] or [Stop] key is pressed,
the machine returns to the initial state of
maintenance mode.

Brother DCP-L2541DW Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Copy Resolution	Up to 600 x 600 dpi
Print Speed	30 ppm
Connectivity	USB, Ethernet
Display	16 characters x 2 lines
Mobile Printing	Brother iPrint&Scan, Google Cloud Print
Scanner Type	Flatbed with ADF
Copy Speed	Up to 30 cpm
Scan Resolution	Up to 600 x 2400 dpi
