Fig. 5-13
For models without keypad
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 54" on the LCD, and
press the [OK] key. For duplex scanning
models, "▲ : ADF ▼ : FB" is displayed
on the LCD. To adjust the ADF scanning
position, press the [▲] key. To adjust the
FB scanning position, press the [▼] key
and proceed to the procedure (2).
For single-side scanning models,
proceed to procedure (2).
(2) To increase the adjustment value, press
the [▲] key. To decrease the adjustment
value, press the [▼] key.
(3) Press the [OK] key after adjusting the
value. "ACCEPTED" is displayed on the
LCD, and the machine returns to the
initial state of maintenance mode.
For models with keypad
(1) Press the [5], and then the [4] key in the
initial state of maintenance mode. For
duplex scanning models, "▲ : ADF ▼ :
FB" is displayed on the LCD. To adjust
the ADF scanning position, press the
[▲] key. To adjust the FB scanning
position, press the [▼] key and proceed
to the procedure (2).
For single-side scanning models,
proceed to procedure (2).
(2) To increase the adjustment value, press
the [▲] key. To decrease the adjustment
value, press the [▼] key.
(3) Press the [SET] or [OK] key after
adjusting the value. "ACCEPTED" is
displayed on the LCD, and the machine
returns to the initial state of maintenance
mode.
Note:
• When the [Stop] key is pressed,
the machine stops correcting the
adjusting value and returns to the
initial state of maintenance mode.
Note:
• When the [X] or [Stop] key is
pressed, the machine stops
correcting the adjusting value and
returns to the initial state of
maintenance mode.
