Brother DCP-L2541DW Service Manual

2-41
Confidential
 Error code 6101
The new toner sensor detected that the toner cartridge was not set.
 Error code 6801
The side thermistor of the fuser unit or the internal temperature sensor detected a
temperature higher than the specified value.
No Toner
Open the Front Cover, then install Toner Cartridge.
<User Check>
• Set the toner cartridge correctly.
• Replace the toner cartridge with a new one.
Step Cause Remedy
1
New toner actuator coming off Reattach the new toner actuator.
2
Connection failure of the new
toner sensor PCB flat cable
Reconnect the new toner sensor PCB flat
cable.
3
New toner sensor PCB failure Replace the new toner sensor PCB ASSY.
4
Main PCB failure Replace the main PCB ASSY.
Cooling Down
Wait for a while
<User Check>
• Lower the room temperature.
• Keep the machine away from heating appliances.
Step Cause Remedy
1
Side thermistor failure Replace the fuser unit.
2
Main PCB failure Replace the main PCB ASSY.

Brother DCP-L2541DW Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Copy Resolution	Up to 600 x 600 dpi
Print Speed	30 ppm
Connectivity	USB, Ethernet
Display	16 characters x 2 lines
Mobile Printing	Brother iPrint&Scan, Google Cloud Print
Scanner Type	Flatbed with ADF
Copy Speed	Up to 30 cpm
Scan Resolution	Up to 600 x 2400 dpi
