Brother DCP-L2541DW Service Manual

2-56
Confidential
 Error code D200
Detected the modem PCB was not connected.
 Error code D800
An error occurred while initializing the touch panel.
Error code D900
Communication between the panel PCB and main PCB was unable while initializing the
touch panel.
 Error code DA00
There was no response from the panel PCB for the specified time after initializing the panel
PCB.
Machine Error
Unplug machine, then call Brother.
Step Cause Remedy
1
Connection failure of the
modem flat cable
Reconnect the modem flat cable.
2
Modem PCB failure Replace the modem PCB ASSY.
3
Main PCB failure Replace the main PCB ASSY.
Print Unable D8
Turn the power off and then back on again.
-
<User Check>
• Check that there is no object on the touch panel.
• Install the latest firmwares (panel firmware and main firmware).
Step Cause Remedy
1
Connection failure of the touch
panel flat cable
Reconnect the touch panel flat cable.
2
Touch panel failure Replace the touch panel ASSY.
3
Main PCB failure Replace the main PCB ASSY.
-
<User Check>
• Install the latest firmwares (panel firmware and main firmware).
Step Cause Remedy
1
Touch panel failure Replace the touch panel ASSY.
2
Main PCB failure Replace the main PCB ASSY.

Brother DCP-L2541DW Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	35 sheets
Copy Resolution	Up to 600 x 600 dpi
Print Speed	30 ppm
Connectivity	USB, Ethernet
Display	16 characters x 2 lines
Mobile Printing	Brother iPrint&Scan, Google Cloud Print
Scanner Type	Flatbed with ADF
Copy Speed	Up to 30 cpm
Scan Resolution	Up to 600 x 2400 dpi
