Brother MFC-7360N Service Manual

x
Confidential
For USA and Canada
 Standard telephone and FCC notices (MFC only)
These notices are in effect on models sold and used in the United States only.
When programming emergency numbers or making test calls to emergency numbers:
• Remain on the line and briefly explain to the dispatcher the reason for the call before
hanging up.
• Perform these activities in the off-peak hours, such as early morning or late evening.
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the
ACTA. On the backside of this equipment is a label that contains, among other information, a
product identifier in the format US: AAAEQ##TXXXX. If requested, this number must be
provided to the telephone company.
You may safely connect this equipment to the telephone line by means of a standard modular
jack, USOC RJ11C.
A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements adopted by the
ACTA. A compliant telephone cord and modular plug is provided with this product. It is
designed to be connected to a compatible modular jack that is also compliant. (See
installation instructions for details.)
The REN is used to determine the number of devices that may be connected to a telephone
line. Excessive RENs on a telephone line may result in the devices not ringing in response to
an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To
be certain of the number of devices that may be connected to a line, as determined by the
total RENs, contact the local telephone company. For products approved after July 23, 2001,
the REN for this product is part of the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point
(e.g., 06 is a REN of 0.6). For earlier products, the REN is separately shown on the label.
If this equipment causes harm to the telephone network, the telephone company will notify
you in advance that temporary discontinuance of service may be required. But if advance
notice is not practical, the telephone company will notify the customer as soon as possible.
Also, you will be advised of your right to file a complaint with the FCC if you believe it is
necessary.
The telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the telephone
company will provide advance notice in order for you to make necessary modifications to
maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information, please
contact Brother Customer Service. (See Brother numbers in the Basic User's Guide.) If the
equipment is causing harm to the telephone network, the telephone company may request
that you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state public utility
commission, public service commission or corporation commission for information.
If your home has specially wired alarm equipment connected to the telephone line, ensure
the installation of this equipment does not disable your alarm equipment. If you have
questions about what will disable alarm equipment, call your telephone company or a
qualified installer.
If you are not able to solve a problem with your product, call Brother Customer Service. (See
Brother numbers in the Basic User's Guide.)
WARNING
For protection against the risk of electrical shock, always disconnect all cables from
the wall outlet before servicing, modifying or installing the equipment.

Brother MFC-7360N Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Scan to	E-mail, File, Image, OCR
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Dimensions (WxDxH)	405 x 399 x 316 mm
All-in-one functions	Copy, Fax, Print, Scan
Compatible operating systems	Linux Mac OS X 10.4.11, 10.5.x, 10.6x Windows 7, Vista, XP, 2000
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	14.4 Kbit/s
Fax speed dialing (max numbers)	208
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	32 MB
Processor family	ARM
Compatible memory cards	Not supported
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	0.9 W
Power consumption (PowerSave)	65 W
Power consumption (average operating)	495 W
Package weight	14800 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	10000 pages per month
