Brother MFC-7440N Network User's Guide

Network printing from Windows
®
: basic TCP/IP Peer-to-Peer printing
36
5
Configuring the standard TCP/IP port 5
Printer driver not yet installed 5
a Put the supplied CD-ROM into your CD-ROM drive. If the model name screen appears, choose your
machine. If the language screen appears, choose your language.
b The CD-ROM main menu will appear. Click Install Other Drivers or Utilities.
c Click Printer Driver (Only, for Network).
d Click Next in response to the Welcome message. Follow the on-screen instructions.
e Choose Standard Installation and click Next.
f Choose Brother Peer-to-Peer Network Printer, and then click Next.
g Follow the on-screen instruction, and then click OK.
Note
Contact your administrator if you are not sure about the location and name of the printer on the network.
h Continue through the wizard clicking Finish when complete.
Printer driver already installed 5
If you have already installed the printer driver and wish to configure it for network printing, follow these steps:
a For Windows Vista
®
:
Click the Start button, Control Panel, Hardware and Sound, and then Printers.
For Windows
®
XP and Windows Server
®
2003:
Click the Start button and choose Printers and Faxes windows.
For Windows
®
2000.
Click the Start button and choose Settings and then Printers.
b Right click on the printer driver you wish to configure, and then choose Properties.
c Click the Ports tab and click Add Port.
d Choose the port that you wish to use. Typically this would be Standard TCP/IP Port. Then click the
New Port... button.
e The Standard TCP/IP Port Wizard will start.
f Enter the IP address of your network printer. Click Next.
g Click Finish.
h Close Printer Ports and Properties dialog box.

Brother MFC-7440N Specifications

General

Print technology	Laser
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Internal memory	32 MB
Mac compatibility	Yes
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	75 W
Power consumption (average operating)	10, 320 W
Standard interfaces	Ethernet
Faxing	Mono faxing
Fax memory	400 pages
Fax coding methods	MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	200
Maximum input capacity	250 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	428 x 396 x 304 mm
Networking features	10/100BaseTX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000 Mac OS X 10.2.4 en recenter Linux printerdriver
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	22 cpm
Display	LCD
Market positioning	Home & office
Bundled software	ScanSoft Paperport 11SE met OCR voor Windows Newsoft Presto! PageManager7 voor Macintosh
Package weight	14.900 g
