Brother MFC-7440N Network User's Guide

Appendix A
69
A
Using RARP to configure the IP address A
The Brother print server’s IP address can be configured using the Reverse ARP (RARP) facility on your host
computer. This is done by editing the /etc/ethers file (if this file does not exist, you can create it) with an
entry similar to the following:
00:80:77:31:01:07 BRN008077310107
Where the first entry is the Ethernet address (MAC address) of the print server and the second entry is the
name of the print server (the name must be the same as the one you put in the /etc/hosts file).
If the RARP daemon is not already running, start it (depending on the system the command can be rarpd,
rarpd -a, in.rarpd -a or something else; type man rarpd or refer to your system documentation for
additional information). To verify that the RARP daemon is running on a Berkeley UNIX
®
based system, type
the following command:
ps -ax | grep -v grep | grep rarpd
For AT&T UNIX
®
-based systems, type:
ps -ef | grep -v grep | grep rarpd
The Brother print server will get the IP address from the RARP daemon when the printer is powered on.
Using APIPA to configure the IP address A
The Brother print server supports the Automatic Private IP Addressing (APIPA) protocol. With APIPA, DHCP
clients automatically configure an IP address and subnet mask when a DHCP server is not available. The
device chooses it's own IP address in the range 169.254.1.0 through to 169.254.254.255. The subnet mask
is automatically set to 255.255.0.0 and the gateway address is set to 0.0.0.0.
By default, the APIPA protocol is enabled. If you want to disable the APIPA protocol, you can disable it using
control panel of the machine. For more information, see APIPA on page 25.
If the APIPA protocol is disabled, the default IP address of a Brother print server is 192.0.0.192. However,
you can easily change this IP address number to match with the IP address details of your network.
Using ARP to configure the IP address A
If you are unable to use the BRAdmin application and your network does not use a DHCP server, you can
also use the ARP command. The ARP command is available on Windows
®
systems that have TCP/IP
installed as well as UNIX
®
systems. To use ARP enter the following command at the command prompt:
arp -s ipaddress ethernetaddress
ping ipaddress
Where ethernetaddress is the Ethernet address (MAC address) of the print server and ipaddress is the
IP address of the print server. For example:

Brother MFC-7440N Specifications

General

Print technology	Laser
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Internal memory	32 MB
Mac compatibility	Yes
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	75 W
Power consumption (average operating)	10, 320 W
Standard interfaces	Ethernet
Faxing	Mono faxing
Fax memory	400 pages
Fax coding methods	MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	200
Maximum input capacity	250 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	428 x 396 x 304 mm
Networking features	10/100BaseTX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000 Mac OS X 10.2.4 en recenter Linux printerdriver
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	22 cpm
Display	LCD
Market positioning	Home & office
Bundled software	ScanSoft Paperport 11SE met OCR voor Windows Newsoft Presto! PageManager7 voor Macintosh
Package weight	14.900 g
