b Using the document guidelines on the
left and top, place the document in the
upper left hand corner with the
document face down on the scanner
glass.
c Close the document cover.
CAUTION
If you are scanning a book or thick
document, DO NOT slam the cover down or
press on it.
Scannable area 2
The scannable area depends on the settings
in the application you are using. The figures
below show unscannable areas.
Usage Document
Size
Top (1)
Bottom (2)
Left (3)
Right (4)
Fax Letter 0.12 in.
(3 mm)
0.16 in.
(4 mm)
A4 0.12 in.
(3 mm)
(Scanner
Glass)
0.12 in.
(3 mm)
(ADF)
0.04 in.
(1 mm)
Legal 0.12 in.
(3 mm)
0.16 in.
(4 mm)
Copy All paper
sizes
0.12 in.
(3 mm)
0.12 in.
(3 mm)
Scan All paper
sizes
0.12 in.
(3 mm)
0.12 in.
(3 mm)
3
4
1
2
