44
For Network Users
Web Based Management
(web browser)
The Brother print server is equipped with a web server
that allows you to monitor its status or change some
of its configuration settings, using HTTP (Hyper Text
Transfer Protocol).
a Open your browser.
b Type http:// printer_ip_address /into your
browser (Where “printer_ip_address” is the IP
address of the printer or the print server name).
For example http://192.168.1.2/
Print the Network
Configuration List
You can print the Network Configuration List to
confirm the current network settings. To print the
Network Configuration List:
a Turn on the machine and wait until the machine
is in the Ready state.
b Press Menu, 6, 6.
Print Reports
6.Network Config
c Press Start.
The machine will print the current network
settings.
Restore the network settings to
factory default
To restore all network settings of the internal
Print/Scan server to factory default, please follow the
steps below.
a Make sure the machine is not operating, then
disconnect all the cables from the machine
(except the power cord).
b Press Menu, 7, 0.
Network
0.Network Reset
c Press 1 to choose Reset.
d Press 1 to choose Yes.
e The machine will restart, re-connect cables
once this is complete.
Note
The User Name is ‘admin’ and the default
password is ‘access’. You can use a web
browser to change this password.
We recommend Microsoft
®
Internet Explorer
®
6.0 (or higher) or Firefox 1.0 (or higher) for
Windows
®
and Safari 4.0/5.0 for Macintosh.
Please also make sure that JavaScript and
cookies are always enabled in whichever
browser you use. To use a web browser, you
will need to know the IP address of the print
server. The IP address of the print server is
listed on the Network Configuration List.
See Chapter 11 of the Network User’s Guide.

Other manuals for Brother MFC-9325CW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-9325CW and is the answer not in the manual?

Brother MFC-9325CW Specifications

General IconGeneral
DVD/CD printingNo
Print technologyLED
Maximum resolution2400 x 600 DPI
Economical printingYes
Print speed (black, normal quality, A4/US Letter)19 ppm
Fax compatibilityITU-T G3
Dimensions (WxDxH)429.3 x 490.2 x 391.8 mm
All-in-one functionsCopy, Fax, Print, Scan
Connectivity technologyWired & Wireless
Display number of colorsMonochrome
Color all-in-one functionscopy, fax, print, scan
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle25000 pages per month
Recommended duty cycle1500 pages per month
Number of print cartridges4
Page description languagesBR-Script 3, PCL 6
Copier resize25 - 400 %
Maximum copy resolution- DPI
Maximum number of copies35 copies
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)19 cpm
Scan toCIFS, E-mail, File, FTP, Image, OCR, USB
Scanner typeFlatbed scanner
Input color depth48 bit
Maximum scan areaA4 / Letter (216 x 297) mm
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
Fax memory600 pages
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed2 sec/page
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity100 sheets
Total number of input trays2
Multi-Purpose tray input capacity1 sheets
Maximum print size216 x 356 mm
Paper tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
DisplayLCD
Market positioningBusiness
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards802.11b, 802.11g
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory576 MB
Sound power level (standby)30 dB
Sound pressure level (copying)53 dB
AC input voltage120 V
AC input frequency50 - 60 Hz
Power consumption (standby)75 W
Power consumption (PowerSave)12 W
Power consumption (average operating)480 W
Package weight28490 g
Operating relative humidity (H-H)20 - 80 %
