Brother MFC-9340CDW Quick Setup Guide

3
2
Remove the packing
material from the
machine
CAUTION
CAUTION
DO NOT eat the silica gel pack, please throw it
away. If ingested, seek medical attention
immediately.
a Remove the packing tape from the outside of
the machine, the silica gel pack on the support
flap and the film covering the scanner glass.
b Fully open the top cover by lifting the handle up
a.
c Slide all eight yellow drum locks in the direction
of the arrows (the locks may require a firm
push).
d Take out all four drum and toner cartridge
assemblies.
e Remove the orange packing piece from the belt
unit.
IMPORTANT
DO NOT connect the AC power cord yet.
IMPORTANT
To avoid print quality problems, DO NOT touch
the shaded part shown in the illustration.

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
