h Put the belt unit back into the machine.
Make sure the belt unit is level and fits
firmly into place.
i Install orange packing materials to the
drum unit as follows:
To secure the toner cartridges, install
the matching orange packing strips
(1) (marked L and R) to the drum unit
on the left and right sides, as shown
in the illustration.
Attach the orange packing strip (2) to
the left side of the drum unit, as
shown in the illustration.
Slide the small orange packing
material (3) onto the metal shaft on
the right side of the drum unit, as
shown in the illustration.
