86
Installing extra memory B
a Turn off the machine’s power switch.
Unplug the telephone line cord.
b Disconnect the interface cable from the
machine, and then unplug the power
cord from the AC power outlet.
Be sure to turn off the machine’s power
switch before you install or remove the
SO-DIMM.
c Remove the plastic (1) and then
metal (2) SO-DIMM covers.
d Unpack the SO-DIMM and hold it by its
edges.
To prevent damage to the machine from
static electricity, DO NOT touch the
memory chips or the board surface.
e Hold the SO-DIMM by the edges and
align the notches in the SO-DIMM with
the protrusions in the slot. Insert the
SO-DIMM diagonally (1), then tilt it
toward the interface board until it clicks
into place (2).
f Put the metal (2) and then the plastic (1)
SO-DIMM covers back on.
g Plug the machine’s power cord back into
the AC power outlet first, and then
connect the interface cable.
