Brother MFC-9840CDW - Components

Confidential
Ref.1-1
REFERENCE 1 SPECIFICATIONS
1. COMPONENTS
The equipment consists of the following major components:
Fig. Ref1-1
Joint cover ASSY
Paper tray
Fuser unit
Back cover upper
Paper eject ASSY DX
Back cover ASSY
Transfer HVPS PCB unit
Side cover L ASSY
A
ccess cove
r
Side cover R ASSY
Engine PCB ASSY
Paper feed
frame unit
THM/HUM sensor
holder ASSY
Main PCB
A
SS
Y
Frame unit
Panel unit
NCU unit
Laser unit
Charge HVPS PCB ASSY
Develop gear
plate ASSY
Drum drive ASSY
Drive frame unit ASSY
Develop press
drive L ASSY
PS PCB unit
Belt unit drive motor ASSY
Front door unit ASSY
A
DF unit
Document scanner unit
Speaker ASSY
Driver PCB ASSY
DX feed ASSY
