3-21
Confidential
13 Lower side cover
14 Power supply PCB ASSY
Cable guide
Ferrite core
Ferrite core
Cable guide
Cable guide
Cable guide
ASF motor harness
Lower side cover
Cap cam harness
Carriage motor harness
Carriage motor
Lower side cover
harness
A view
<A view>
Maintenance cam
harness
Cable guide
Ferrite core
Lower power supply frame
AC cord ASSY
Cable guide
Cable guide
PS insulator
