3-23
Confidential
17 Control panel ASSY
18 Registration sensor harness
Cable guide
Cable guide
Cable guide
Control panel ASSY
Cable guide
Panel flat cable
Main PCB
Flat core
Touch panel FG wire
Main PCB
harness holder
Cable guide
Registration sensor harness
Registration sensor PCB
Frame CR unit
DX paper guide
Inner chute ASSY
