2-48
Confidential
Error code 8C00
There is no paper set in the manual feed slot on the manual feed slot fix mode.
Error code 8E01
The paper size setting for the machine is other than A4, Letter, Legal or Folio when receiving
fax.
Error code 8E02
Detected that the size of the paper set to paper tray was over 10 mm shorter than letter size
when receiving fax or printing a list/report.
Manual Feed
Load paper.
<User Check>
• Set paper in the manual feed slot.
Step Cause Remedy
1
Registration front actuator
caught in some sections of the
machine
Reattach the registration front actuator.
2
Connection failure of the
registration rear sensor harness
Reconnect the registration front/rear sensor
PCB harness.
3
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
4
HVPS flat cable breakage Replace the HVPS flat cable.
5
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
6
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
7
Main PCB failure Replace the main PCB ASSY.
Size mismatch
Fax received. Set correct paper size in menu.
Size mismatch
Reload correct paper, then press Start.
<User Check>
• Set A4 or Letter size paper.
Step Cause Remedy
1
Registration rear actuator
caught in some sections of the
machine
Reattach the registration rear actuator.
2
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
3
Main PCB failure Replace the main PCB ASSY.
To Next Page
